SIEMENS CP343-1 Ethernet Module: 6GK7343-1EX30-OEXO – Industrial Automation Solution

Model Type:Communication Processor

Model Number:6GK7343-1EX30-OEX0

Manufacturer:SIEMENS

Net Weight (kg):0.299

Packaging Dimension:13,20 x 14,80 x 5,10 cm

Connection:Industrial Ethernet via TCP/IP and UDP

Multicast Support:Yes

Communication Protocols:ISO, TCP/IP, UDP, S7 Communication

Fetch/Write Capability:Yes

SEND/RECEIVE:With and without RFC1006

PROFINET IO Device:Integrated 2-port switch ERTEC 200

Module Replacement:Without PG

SNMP Diagnostics:Available

Initialization via LAN:Supported

RJ45 Connections:2x 10/100 Mbit/s

Diagnostic Add-ons:Multicast, Chargeable Communication Modules

Network Synchronization:NTP-CPU Sync

Network Speed:10/100 MBit

    The SIEMENS CP343-1 Ethernet Module, 6GK7343-1EX30-OEX0, is a critical component for enhancing the networking capabilities of SIMATIC S7-300 systems. This compact module is meticulously designed for industrial applications, ensuring reliable and efficient data transmission over Ethernet networks.

    With support for ISO, TCP/IP, UDP, and S7 Communication protocols, this module seamlessly integrates with existing industrial automation systems, facilitating enhanced control and monitoring functionalities. Its capability to perform fetch/write operations and SEND/RECEIVE data transfers with and without RFC1006 further enriches its operational versatility.

    The integrated 2-port switch ERTEC 200 provides a flexible network interface, allowing for the efficient management of data traffic between different components of an industrial setup. The module’s ability to replace communication devices without the need for a programming station (PG) ensures ease of maintenance and quick turnaround times during system upgrades or repairs.

    Equipped with SNMP diagnostics, the CP343-1 offers advanced monitoring tools for system administrators, enabling proactive identification and resolution of network issues. Initialization via LAN streamlines the setup process, minimizing downtime and enhancing user convenience. Additionally, the support for multicast and chargeable communication modules allows for scalable network configurations tailored to specific business needs.

    This Ethernet module’s adherence to international standards for industrial connectivity and its robust design make it an indispensable asset in any industrial automation project. Whether you’re looking to upgrade your existing system or build a new one, the SIEMENS CP343-1 ensures that your industrial network operates at peak efficiency, contributing to overall productivity and cost savings.
