Manufacturer:General Electric
Model:IP-QUADRATURE
Type:Quadrature Encoder Module
Resolution:Up to 10,000 PPR
Output Signal:TTL/HTL
Supply Voltage:5VDC / 12VDC / 24VDC
Operating Temperature Range:-20°C to +85°C
Mechanical Life:50 million pulses
Shaft Diameter:6mm or 8mm
Weight:150g
Dimensions:60mm x 30mm x 20mm
The GE IP-QUADRATURE is a high-precision quadrature encoder designed to deliver accurate and reliable position and speed feedback. It is ideal for use in harsh industrial environments where precision and durability are paramount.
This encoder offers resolutions up to 1000 lines per revolution, providing exceptional accuracy and reliability. It operates within a wide voltage range from 10-30 VDC, making it compatible with a variety of industrial control systems.
The IP-QUADRATURE is built with robust materials to withstand the rigors of industrial use, boasting a protection rating of IP65. This ensures dust-tight and water-resistant performance, making it suitable for a wide range of applications.
The encoder supports push-pull or open collector output signals, providing flexibility for integration with different control systems. It includes A, B, Z, and Index output channels for enhanced functionality and redundancy.
With a mechanical life exceeding 50 million pulses, the GE IP-QUADRATURE is designed for long-term reliability and minimal maintenance. Its wide operating temperature range from -20°C to +85°C makes it suitable for both indoor and outdoor use.
