Product Type:Axis Controller Module
Counter Resolution:24 bit
Inputs:HEDL (HP / AVAGO interface) / RS422
Encoder Power Supply:+5 V or +15 V selectable with jumper
Output Voltage:Low: 0 to 2 V, high: 3 to 34 V, Imax = 10 mA
Voltage Range:18 to 34 VDC
The Bachmann ACR222/2 is a cutting-edge Axis Controller Module that offers unparalleled performance for industrial automation applications. With its 24-bit counter resolution, it ensures accurate and responsive control over motors and machinery.
Equipped with a versatile input system, the ACR222/2 supports both HEDL (HP / AVAGO interface) and RS422 protocols, enabling seamless integration with various control systems and devices.
Featuring a flexible encoder power supply, users can select between +5 V or +15 V, depending on their specific application requirements. This feature enhances compatibility across different systems and reduces the need for external power supplies.
The output voltage configuration offers a low range from 0 to 2 V and a high range from 3 to 34 V, with a maximum current draw of 10 mA. This wide range ensures that the module can handle a variety of load types, from small actuators to larger motors, providing efficient and reliable operation.
Operating within a robust voltage range of 18 to 34 VDC, the ACR222/2 is designed to withstand the harsh conditions often encountered in industrial environments. Its compact yet durable design ensures long-lasting reliability and minimal maintenance requirements.
