Allen Bradley 1756-DNB/C ControlLogix DeviceNet Communication Module

Model Type:DeviceNet Bridge Module

Manufacturer:Allen Bradley

Model Number:1756-DNB/C

Current Rating:Drawn: 400 mA at 5.1 V

Mounting:Chassis

Communication Protocol:DeviceNet

Enclosure:Open Type

RFI Suppression:Radiated: 10 V/M with 1 KHZ Sine-Wave 80% AM from 80 – 2000 MHz, 10 V/M with 200 Hz 50% Pulse 100% AM at 900 MHz, 10 V/M with 200 Hz 50% Pulse 100% AM at 1890 MHz, 3 V/M with 1 KHZ Sine-Wave 80% AM from 2000 – 2700 MHz, Conducted: 10 VRMS with 1 KHZ Sine-Wave 80% AM from 150 KHZ – 80 MHz

Temperature Rating:0 – 60 DEG C

Power Dissipation:5.1 W

Isolation:30 V continuous

Environmental Conditions:5 – 95% non-condensing relative humidity

Vibration:2 G

Shock:30 G

Interface:Ethernet

    The Allen Bradley 1756-DNB/C ControlLogix DeviceNet Communication Module is engineered for optimal performance in industrial environments. This robust module ensures reliable and secure communication between PLCs and DeviceNet devices, enhancing operational efficiency and productivity.

    With its advanced design, the 1756-DNB/C module supports multiple communication protocols, including DeviceNet, ensuring compatibility with a wide range of industrial equipment. Its open-type enclosure allows for easy integration into diverse control systems without compromising on functionality or performance.

    Equipped with state-of-the-art RFI suppression technology, this module effectively mitigates electromagnetic interference, ensuring stable data transmission even in noisy environments. The continuous isolation feature further guarantees high-level protection against electrical hazards, safeguarding system integrity.

    Designed for demanding industrial conditions, the Allen Bradley 1756-DNB/C module operates within a temperature range of 0 – 60 DEG C, ensuring reliability in extreme environments. Its compact size and rugged construction make it suitable for installation in space-constrained areas without sacrificing performance.

    This communication module offers unparalleled ease of use with its straightforward interface and comprehensive compatibility. It seamlessly integrates into existing control networks, minimizing setup time and maximizing operational efficiency. Trust in Allen Bradley’s expertise to deliver a solution that meets the highest standards of industrial automation.
