ABB 3BHE022678R0105 GD D830 B105 GATE DRIVE – ABB

Product Type:Gate Drive Module

Brand:ABB

Model:GD D830 B105

Order Number:3BHE022678R0105

Certified Product:Yes

Series:GD D830 B105

Material Coding:3BHE022678R0105

Power Rating:24VDC

Current Rating:30A

Frequency:50/60Hz

Cooling Method:Air Cooling

Operating Temperature Range:-20°C to +55°C

Storage Temperature Range:-40°C to +70°C

Dimensions (HxWxD):120mm x 110mm x 40mm

Weight:0.5kg

Interface Type:Digital Input/Output

Communication Protocol:RS485 Modbus

Protection Class:IP20

Safety Certification:IEC 61800-5-1, EN 61800-5-2

    Introducing the ABB GD D830 B105 Gate Drive, engineered to revolutionize gate control systems in industrial environments. This advanced drive is equipped with cutting-edge technology that ensures seamless integration with existing infrastructure, enabling effortless scalability and compatibility with a wide range of industrial protocols.

    Featuring a robust design with a high power output of 105 A, this drive is capable of handling demanding gate operations with ease. Its versatile frequency range from 40-60 Hz ensures optimal performance across different applications, from small-scale residential gates to large industrial gates.

    Equipped with a comprehensive set of features, including Profibus DP control protocol support, the GD D830 B105 offers unparalleled reliability and precision. It comes with an overload capability of 150% for 1 minute, providing a safety margin even under extreme conditions.

    With its IP21 protection class, the drive is designed to withstand harsh industrial environments, ensuring continuous operation regardless of external factors. Additionally, it operates efficiently within a temperature range of -20°C to +50°C, making it suitable for various climates and locations.

    Ease of use and maintenance are at the forefront of the GD D830 B105’s design. The modular construction allows for easy installation and quick troubleshooting, reducing downtime and maintenance costs. Furthermore, the drive’s compact size and sleek design enhance its aesthetic appeal and space utilization within industrial settings.
