Input Voltage Range:300V to 500V DC
Output Current:Up to 100A
Switching Frequency:Up to 20kHz
Protection Features:Overvoltage, undervoltage, overcurrent protection
Operating Temperature Range:-40°C to +85°C
Dimensions (WxHxD):100mm x 80mm x 30mm
Weight:0.5kg
The AB 1336-BDB-SP5D Gate Drive is engineered with the latest semiconductor technology, ensuring reliable and efficient operation in various industrial environments. Its robust design allows for seamless integration into existing systems, minimizing downtime and enhancing productivity.
Key features include adjustable voltage and current outputs, enabling precise control over actuators, motors, and other power-consuming devices. This makes it an indispensable component in automation, robotics, and manufacturing systems where accuracy and reliability are paramount.
The gate drive supports a wide range of power sources, accommodating both direct current (DC) and alternating current (AC) inputs, making it versatile for different application scenarios. Its ability to handle high-frequency signals ensures compatibility with modern digital control systems.
Featuring a compact footprint, the AB 1336-BDB-SP5D Gate Drive is designed for easy installation and maintenance, reducing the overall system complexity and cost. Its operating temperature range (-20°C to +60°C) ensures reliability across diverse climates, making it suitable for outdoor or harsh industrial conditions.
With its high power factor of ≥ 0.9, the module minimizes energy losses, contributing to more efficient power usage and lower operational costs. The built-in safety features protect against short circuits and overloads, safeguarding connected equipment from damage.
